Mindrill MHD100 Hydraulic Drifter
The Mindrill MHD100 is a compact yet powerful hydraulic percussive top hammer rock drill engineered for high-performance and reliability in demanding conditions. This low-profile drifter is ideal for underground mining and tunnelling applications and ensures optimal drilling efficiency with air flushing (with optional water flushing).
Key Features of the Mindrill MHD100 Hydraulic Drifter
Ideal for line drilling in the dimensional stone industry, horizontal drilling, foundation drilling, road cutting, trenching, and bolting
✅ Proven design globally
✅ Compatible with a wide range of drill rigs
✅Built-in air flushing (water flushing optional)
✅ Compact size and low profile height
✅ Biodegradable oils can be used to reduce environmental impact
✅ Parts interchangeable with Sandvik HLX1 Hydraulic Rockdrill.
Technical Specifications
✅Weight: 50 kg
✅Length: 479 mm
✅Hole Diameter Drilling: 22-45 mm
✅Power Class: 6.5 kw
✅Shank Size : 22 x 108 mm
✅Operating pressure Percussion: 100 – 180 bar
✅Percussion rate: 70 – 88 Hz
✅High pressure (HP): 50 bar
✅Low pressure (LP): 4 bar
✅Air pressure : 3-5 bar
✅Flushing pressure (air/water): Max.5 bar
✅Oil consumption: 50 – 100 g/h
✅Drill steels: Integral rods
✅Rotation motor type: OMM32
✅Filling valve: Vg8 DIN7756
✅Accumulator gas: Nitrogen N2
